4X4 5ton mini dump tipper Dongfeng truck

FOB Reference Price:Get Latest Price
  • >=1
    US $25850.00
Supply Ability:
300 Piece/Pieces per Month
Port:
China any port
Report Suspicious Activity
Overview
Quick Details
Drive Wheel:
4x4
Capacity (Load):
1 - 10t
Horsepower:
150 - 250hp
Condition:
New
Transmission Type:
Manual
Emission Standard:
Euro 3
Fuel Type:
Diesel
Engine Capacity:
4 - 6L
Gross Vehicle Weight:
6360
Place of Origin:
Hubei, China (Mainland)
Brand Name:
Dongfeng
Model Number:
EQ3042G1
Dimensions (L x W x H) (mm):
6900X2475X2790
Color:
can be chosne by customer
Packaging & Delivery
Packaging Details
naked,RORO or container ,the vehicle surface spray anti-rust wax.
Delivery Time
30 day
Product Description

  Dongfeng EQ3042G1 5T 4x4 mini tipper Truck

Size

Overall dimension(mm)

6900x2475x2790

Box size(mm)

4500x2300x800

Wheelbase(mm)

3800

Suspension front/rear(mm)

1250/1850

Wheel span front/rear(mm)

1580/1560

Weight

Max gross weight(kg)

6360

Curb weight(kg)

3360

Load weight(kg)

3000

Front axle load weight(kg)

2700

Rear axle load weight(kg)

7000

Performance

Min turning diameter(m)

≤15

Top speed(km/h)

85

Climbing ability(%)

≥30%

Full load brake distance(30km/h)

≤7

Slope brake

≥20%

Emergency brake distance(30km/h)

≤20

Engine parameters

Engine type

In line 4cylinder,4 stroke water-cooling,

turbocharge diesel engine

Engine model

B140-33

diesel engine

Fuel tank

capacity

80L

Bore/Stroke

102x120mm

Displacement

3.9L

Exhaust

Euro III

Power

103kw/140hp

Max torque

502N.M/2500rpm

Start voltage

28V

Clutch

Clutch type

Single dry diaphragm spring

Friction plate diameter

275

Transmission

Gear box

Manual 5 speed

Steering system

Type

 Power steering wheel

Brake system

Brake type

Drum front/rear

Brake system type

Air brake

Chassis frame

Chassis type

Integral type

Tire

Tire number

6+ 1 Spare tire

Tire model

9.00-20

A/C

Option



Packaging & Shipping




Our Services

                  ·         One year quality warranty for key parts such as axles, engine, transmission;

·         All spare parts would be OEM and supplied at cost prices;

·         Overseas service center to ensure efficent after-sales service;

·         Regular after-sales visit to collect information about the vehicle's working status and feedback from customers.
